Detail
Lens focal length 3.6mm
Maximum aperture F0.9
Image sensor 1/1.8" CMOS,4MP 2560(H)*1440(V)
Lens aperture type fixed aperture
Lens viewing angle Horizontal: 93°; Vertical: 49.6°
White light fill light distance 30m
Video encoding format MJPEG/H.264/H.265
Smart Coding Extra265/264
Video frame rate 30/25fps can be set
Scene adaptive, backlight adaptive, fog-penetrating adaptive
Minimum illumination Color: 0.001Lux (F1.2, AGC ON, 1/30 shutter) Black and white: 0.0001Lux (F1.2, AGC ON, 1/30 shutter)
Day and night mode supported; automatic (ICR)/color/black and white/timing Default color Sensitivity high, medium, low Default high Image trigger/internal trigger
Wide dynamic range 120dB
White balance automatic/manual/one-key trigger
Strong light suppression support
Digital noise reduction 2D/3D noise reduction
Algorithm fog penetration support
Target target detection, target attribute detection
Human body detection
Behavior analysis: fast movement detection, line crossing detection, intrusion detection, area entry/exit detection, loitering detection
Crowd situation analysis: queue length statistics, regional people statistics, people flow statistics
Power supply type DC12V, PoE (IEEE 802.3af)
Power consumption Maximum power consumption: 12.2W, Typical power consumption: 9.6W
Working temperature -30℃~55℃
Working humidity 5%~95% (no condensation)
Lightning protection and surge protection 4kV
Protection grade IP67
Anti-corrosion grade: Class C anti-corrosion
Weight: Whole machine weight 0.50kg; Packing weight 0.68kg
Size Overall machine size 179mm*100mm*84mm; packaging size 252mm*135mm*114mm
