Brand:Honeywell
Model:HCS1WZ5XR30WXXX
lens:5.3 ~ 159mm, F1.6 ~ F4.3
weight:48kg
HCS1WZ5XR30WXXX WDR 30x 5MP Exproof IR PTZ
Honeywell’s latest explosion-protected PTZ network camera is a good fit for onshore, offshore, marine, and heavy industrial
installations in hazardous and challenging environments. The camera features a 316L stainless steel housing certified for hazardous areas
according to IECEx. The housing prevents any interior sparks or explosions from escaping and igniting the gases or dust in the
surrounding air. The HCS1WZ5XR30WXXX cameras provide extremelycrisp video with up to 5 million effective pixels, 30x optical zoom,
and True Day/Night WDR for continuous surveillance in both hazardous and safe area applications.This product comply with the
Essential Health and Safety Requirements relating to the design and construction of products intended for use in potentially explosive atmospheres.
HCS1WZ5XR30WAA2 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, AC100-240V, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port,
2.5m armored cable ,1 Explosion-proof Gland
HCS1WZ5XR30WAU2 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, AC100-240V, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port,
2.5m unarmored cable , 2.5m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WAA3 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, AC100-240V, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port,
3.5m armored cable ,1 Explosion-proof Gland
HCS1WZ5XR30WAU3 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, AC100-240V, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port,
3.5m unarmored cable , 2m + 1.5m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WAA5 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, AC100-240V, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 5m armored cable , 1 Explosion-proof Gland
HCS1WZ5XR30WAU5 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, AC100-240V, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 5m unarmored cable , 2m+2m+1m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WAAA WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, AC100-240V, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 10m armored cable , 1 Explosion-proof Gland
HCS1WZ5XR30WAUA WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, AC100-240V, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 10m unarmored cable , 2m x 5 explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WBU2 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VAC, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 2.5m
unarmored cable , 2.5m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WBU5 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VAC, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 5m
unarmored cable , 2m+2m+1m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WBUA WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VAC, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 10m
unarmored cable , 2m x 5 explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WBU3 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VAC, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 3.5m unarmored cable , 2m + 1.5m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WBA2 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VAC, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 2.5m armored cable ,1 Explosion-proof Gland
CS1WZ5XR30WBA5 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VAC, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 5m
armored cable , 1 Explosion-proof Gland
HCS1WZ5XR30WBAA WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VAC, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 10m
armored cable , 1 Explosion-proof Gland
HCS1WZ5XR30WBA3 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VAC, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 3.5m
armored cable ,1 Explosion-proof Gland
HCS1WZ5XR30WCU2 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, PoE++(48Vd.c), IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 2.5m unarmored cable , 2.5m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WCU5 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, PoE++(48Vd.c), IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 5m unarmored cable , 2m+2m+1m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WCUA WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, PoE++(48Vd.c), IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 10m unarmored cable , 2m x 5 explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WCU3 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, PoE++(48Vd.c), IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 3.5m unarmored cable , 2m + 1.5m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WCA2 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, PoE++(48Vd.c), IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 2.5m armored cable ,1 Explosion-proof Gland
HCS1WZ5XR30WCA5 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, PoE++(48Vd.c), IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 5m armored cable , 1 Explosion-proof Gland
HCS1WZ5XR30WCAA WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, PoE++(48Vd.c), IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 10m armored cable , 1 Explosion-proof Gland
HCS1WZ5XR30WCA3 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, PoE++(48Vd.c), IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC
port, 3.5m armored cable ,1 Explosion-proof Gland
HCS1WZ5XR30WDU2 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VDC, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 2.5m
unarmored cable , 2.5m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WDU5 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VDC, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 5m
unarmored cable , 2m+2m+1m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WDUA WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VDC, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 10m
unarmored cable , 2m x 5 explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WDU3 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VDC, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 3.5m
unarmored cable , 2m + 1.5m explosion-proof Flexible Tube, 1 Explosion-proof Gland
HCS1WZ5XR30WDA2 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VDC, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 2.5m
armored cable ,1 Explosion-proof Gland
HCS1WZ5XR30WDA5 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VDC, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 5m
armored cable , 1 Explosion-proof Gland
HCS1WZ5XR30WDAA WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VDC, IP68 Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 10m
armored cable , 1 Explosion-proof Gland
HCS1WZ5XR30WDA3 WDR 30x 5MP Exproof IR PTZ, 30x Optical Zoom, 24VDC, IP68Built-in optical fiber convert module, 1 port-single mode single fiber, 1310T/1550R, with FC port, 3.5m
armored cable ,1 Explosion-proof Gland
Explosion-Proof Certification
? IECEx certified with AISI 316L stainless steel construction
? Certified for use in Gas Zone 1 & 2 (Class IIA, IIB, IIC) and Dust Zone
21 & 22 (Class IIIA, IIIB, IIIC)
? Certified temperature for explosion-proof applications: -40°C to
60°C (–40°F to 140°F)
? M25×1.5 threaded hole for use of cable glands or conduit
? IP68 rating guarantees complete protection against harsh weather
? This product is Flameproof, Optical Radiation and Dust Ignition
protection by enclosure.
Flexible Surveillance Solution
? 5MP 30fps, 30x optical zoom and P-Iris lens providing maximum
flexibility to clearly view the target
? H.265, H.264 and MJPEG codec, triple stream support
? Support for unicast and multicast mode for streaming
? ONVIF Profile S, G and T compliant
? Supports Loitering, Intrusion, Tampering, SMD, Motion Detection
analytics
? Contain no content or material from any companies or their
subsidiaries prohibited under US National Defense Authorization Act
(NDAA) Section 889 and can be used as part of video systems which
comply with NDAA Section 889
Easy to Install and Use
? 100~240V AC power input
? Built-in heater
? IIntegrated wiper and washer control system operated from web
client or preset
? 10 meters cable with options unarmoured RJ45 interface and
armoured RJ45 and FC Fiber Optic interface.
? Remote configuration, motorized zoom adjustments and auto focus
through web client
? 5MP high resolution camera to capture more
? 1/2.8" progressive scan image sensor
? Excellent low light performance with min. illumination of 0.005 lux Color
? Multiple, selectable compression formats (H.265 HEVC/H.264/MJPEG)
? People counting, Loitering, Trip wire, SMD
? Tempered glass with sun shroud
? Optional stream encryption – camera to Maxpro under AES256 providing secure data integrity and privacy
? ONVIF Profile S, G and T compliant
? Water resistant IP66, IP68 (2m/2h) ingress protection rating
? 5.3–159 mm, F1.6–F4.3, P-Iris, 30x optical zoom lens
? Up to triple stream support
? Support for Electronic image stabilizer (EIS)
? True WDR: 120 dB
? Global language support with web GUI in 14 languages
? NDAA complaint
? 100~240V AC power input
? Cyber Security
features include signed certificates and data encryption
Features And Benefits
Market Opportunities
The camera features stainless steel housing and offers 5MP high resolution image quality. They are ideally suited for video surveillance
monitoring of onshore, offshore, marine, and heavy industrial environments, such as the oil and gas industries, as well as dusty
environments, such as the paper and textile industries.IEC/ANSI /Cyber security certification for Honeywel
